PROFILED WIRE MESH PANEL FENCING (3D)

2020-08-13

PROFILED WIRE MESH PANEL FENCING (3D)

We provide complex systems made of welded-and-profiled or plain panels, complete with mounting posts and suitable installation accessories.

The fencing panels may be either galvanised with fire or galvanised and powder-painted. We also make gates and wickets suited for the individual needs and requirements of the Customer. We offer both sliding and double-wing gates.

Application: for creating fences around factories, warehouses, public buildings and facilities such as schools, football fields and sports stadiums, playgrounds, and private estates.

We also offer fence-mounting services.

TECHNICAL PARAMETERS

Profiled panels, mesh size 50×200
height [mm]	width [mm]	wire diameter [mm]	embossing	post lights		clamps
height [mm]	width [mm]	wire diameter [mm]	embossing	ø48 mm	60×40 mm	clamps
1030	2500	ø4,0 ø5,0	2V	H - 1,5m		2 sets
1230	2500	ø4,0 ø5,0	2V	H - 2m		2 sets
1530	2500	ø4,0 ø5,0	3V	H - 2m		3 sets
1730	2500	ø4,0 ø5,0	3V	H - 2,4m		3 sets
2030	2500	ø4,0 ø5,0	4V	H - 2,6m		4 sets

Profiled panels, mesh size 70×200
height [mm]	width [mm]	wire diameter [mm]	embossing	post lights		clamps
height [mm]	width [mm]	wire diameter [mm]	embossing	ø48 mm	60×40 mm	clamps
1030	2500	ø4,0	2V	H - 1,5m		2 sets
1230	2500	ø4,0	2V	H - 2m		2 sets
1530	2500	ø4,0	3V	H - 2m		3 sets
1730	2500	ø4,0	3V	H - 2,4m		3 sets
2030	2500	ø4,0	4V	H - 2,6m		4 sets

We can also manufacture fencing panels in other sizes on custom order.

ACCESSORIES

connectors concrete jambs
brick jambs claspings
gate drives posts

FINISH

Our welded mesh panels are made of bare or colour powder-coated galvanised steel wire. Powder coating provides maximum protection against the weather and corrosion. The paint coating process employed by ZPH JAN is done by laying powder coats and curing them at high temperature. The process dissolves the pigment and results in a uniform colour coating of the mesh panel. The process is environmentally friendly.

The fence posts are galvanised and powder coated in colours. The available post sections are tubular or square. Each post comes with a PVC top cap to protect the interior from water.

The standard powder coating colour is RAL 6005 Green. Other colours are available on request.
